Thermicroll S.D. Rolling Doors

Thanks to fast installation times, high speed rolling doors Thermicroll S. D. are ideal for situations where it is necessary to close a passage quickly.

These are extremely versatile industrial doors, both in terms of size and design as well and low maintenance.

Designed for intensive and continuous use, this pvc high speed door guarantees a high degree of insulation with insulated sheet.

Request a quote!
Thermicroll® S.D. - High Speed Rolling Doors

Thermicroll Rolling Doors: features and benefits

The main features of industrial rolling doors are the high response speed, absolute safety and extreme versatility both in terms of size and design.

The special design of the Thermicroll S. D. S. high speed rolling door gives it an unparalleled service life, eliminating the need for extraordinary maintenance. Ordinary maintenance operations are also very limited in time, creating important economic and temporal savings.

These features make Thermicroll® the leading company in the field of design, research and development, as well as the S. D. industrial door an example of a fast and extremely reliable industrial closure.

The industrial door, which uses mechanical and electrical components of the highest quality, is entirely designed and built in Italy, in one of the company’s various locations.

If you want to learn more about the features of Thermicroll industrial shutters, you can see the page dedicated to the advantages of industrial doors.

All our rolling shutters comply with the 12453-12445/EC and UNI EN 13241-1/EC standards and are certified as exclusive and original products, unique in their strength, practicality, functionality and quality.

In the case of Thermicroll S. D. rolling doors are not the right solution for you, you can see the other available models of pvc speed doors: H.S.D. self-repairing, Food Inox, F. U. D. fold-up pack doors.

For more information on the Thermicroll S. D. industrial doors check the table with the technical characteristics and download the catalogue!

Thermicroll® S.D. High Speed Rolling Doors Thermicroll® S.D.

THERMICROLL® S.D.
TECHNICAL SPECIFICATIONS
PARAMETER SPECIFICATIONS
Applications Internal/External
Maximum dimensions (L x H) 6000 x 5000 mm
Maximum opening speed 1 m/s
Maximum closing speed 1 m/s
Operating temperature -20°C +30°C
Wind load
W 3000 x 3000
Class
1
Structure STANDARD
Zinc plated steel
OPTIONAL
Painted galvanized steel / stainless steel
Coat 0.9mm – 900 gr/sqm PVC sheet
Control panel Contactors
Power supply 400 V 16 A 3 Ph
Frequency 50/60 Hz
Limit switch Mechanical
Emergency Release STANDARD
Hand crank release
OPTIONAL
Counterweight
Safety edge (EN 13241) Anti-crushing sensor
Durability 1,000,000,000 opening and closing cycles with regular maintenance every 6 months
